Optical cable armored with round steel wire, center tube design.
Crushing force from 400 N/cm
Tensile force up to 80 kN
Operating temperature from -40°С to +70°С Arctic version from -60°С to +70°С Installation: up to -30°С
For any climatic zones
Fire-safe
Rodent protection
1. Optical fiber.
2. Central tube.
3. Round steel wire.
4. Gel filler.
5. Outer PE sheath.
Custom design is available.
|
Number of optical fibers in cable |
Nominal calculated cable diameter, mm |
Calculated cable weight, kg/km |
Tensile force,kN |
Min.radius of cable bending,mm |
|
OKGTS(n)-00-1х4...1х48...-(4,0) |
||||
|---|---|---|---|---|
|
Up to 24 |
7,6 |
Up to 95 |
4,0 |
152 |
|
Up to 48 |
10,2 |
Up to 205 |
204 |
|
|
OKGTS(n)-00-1х4...1х48...-(8,0) |
||||
|
Up to 24 |
7,6 |
Up to 95 |
8,0 |
152 |
|
Up to 48 |
11,0 |
Up to 268 |
220 |
|
|
OKGTS-00-1х4...1x48...-(20,0) |
||||
|
Up to 24 |
11,8 |
Up to 289 |
20,0 |
236 |
|
Up to 48 |
12,0 |
Up to 285 |
240 |
|
|
OKGTS-00-1х4...1x48...-(80,0) |
||||
|
Up to 24 |
18,0 |
Up to 794 |
80,0 |
360 |
|
Up to 48 |
20,2 |
Up to 856 |
404 |
|
